A502

ATV


Engine100cc, 1 cylinder-4 stroke, air cooled
TransmissionChain drive, full auto clutch
Final Drive13T/37T, 420# chain
Starting SystemElecrtic start only
Fuel Tank Volume
2L
Battery
12V 5Ah
TiresFront & rear 14.5x7-6
OptionalFront & Rear 16x8-7
Brake SystemFront drum brakes and rear hydraulic disc brake
Suspension

A swing arm with double shock absorber

Rear mono shock absorber

Max Speed55kmph
Max Load Capacity75kgs
Wheelbase880mm
Seat Height560mm
Min Ground Clearance90mm
Dry Weight80kgs
Carton Size1150x760x640mm
QTY/Container42pcs/20FT, 122pcs/40HQ
